橡胶船用电缆
CHJPJ85/NC, CHJPF86/NC船用电缆应用
CHJPJ85/NC, CHJPF86/NC船用电缆应用
对数x2x截面积 No of pairs x 2 x cross section area | CHJPJ80/NC, CHJPF80/NC CHJPJ90/NC, CHJPF90/NC | CHJPJ95/NC, CHJPF96/NC | |||||||||
外径 Over diam. mm | 约重 Approx. weight | 外径 Overall diameter | 大约重量 Approx. weight | 外径 Overall diameter | 大约重量 Approx. weight | ||||||
标称 Nom. | 很大 Max. | 标称 Nom. | 很大 Max. | 80系列 | 90系列 | 标称 Nom. | 很大 Max. | 85系列 | 95系列 | ||
No.x 2xmm2 | kg/km | kg/km | kg/km | kg/km | kg/km | ||||||
1x2 x 2.5 2x2 x 2.5 3x2 x 2.5 4x2 x 2.5 5x2 x 2.5 7x2 x 2.5 10x2 x 2.5 12x2 x 2.5 14x2 x 2.5 16x2 x 2.5 19x2 x 2.5 24x2 x 2.5 27x2 x 2.5 30x2 x 2.5 33x2 x 2.5 37x2 x 2.5 43x2 x 2.5 48x2 x 2.5 | 10.6 16.2 17.5 19.5 21.4 23.6 30.9 32.0 33.9 36.0 38.2 45.3 46.6 48.3 50.5 52.7 57.6 61.0 | 12.0 17.5 19.0 21.0 23.0 25.5 33.0 34.0 36.0 38.5 41.0 48.0 49.5 51.5 53.5 56.0 61.0 64.5 | 125 240 325 417 501 667 973 1122 1293 1468 1715 2178 2421 2651 2907 3235 3765 4186 | 12.2 17.8 19.1 21.1 23.0 25.2 33.0 34.1 36.0 38.1 40.3 47.4 48.7 50.4 52.6 54.8 59.7 63.1 | 13.5 19.0 20.5 22.5 24.5 27.0 35.0 36.5 38.5 40.5 43.0 50.5 51.5 53.5 56.0 58.0 63.0 67.0 | 222 388 487 600 704 896 1363 1531 1731 1938 2221 2783 3053 3312 3605 3973 4582 5061 | 211 371 469 580 682 872 1321 1488 1685 1889 2169 2722 2989 3247 3537 3902 4504 4979 | 14.3 20.1 21.6 23.6 25.7 27.9 36.1 37.4 39.3 41.6 43.8 51.3 52.6 54.5 56.7 59.1 64.2 67.8 | 15.5 21.5 23.0 25.0 27.5 29.5 38.5 39.5 41.5 44.0 46.5 54.5 55.5 57.5 60.0 62.5 68.0 71.5 | 277 472 584 703 825 1022 1554 1740 1945 2178 2466 3108 3376 3664 3965 4364 5024 5547 | 266 456 566 683 803 998 1512 1696 1899 2129 2414 3047 3313 3599 3897 4293 4946 5465 |
注: 上述参数仅供参考 ，如需接纳须经我司手艺部分确认。上述任何参数修改恕不另行通知。
Note: Data above only for reference, confirmation needed by our technical department. We reserve the right to alter all information without notice.
