CHJPJ/SC船用电缆CHJPF/SC系列
CHJPJ/SC船用电缆CHJPF/SC系列
150/250V
交联聚乙烯绝缘低烟无卤船用通信电缆
XLPE insulated halogen-free low-smoke shipboard symmetrical communication calbe
图例 Example:
CHJPJ85/SC
7X2X0.75
用途 Application
船用通讯电缆可用于电信、电子盘算机、信息处置惩罚设 备中的信号传输和控制系统。对冶金、化工、电力等 工矿企业亦同样适用。
The cable is intended for telecommunication, computer and information processing unit of shipboard and naval ship and it is also available to metallurgical insdustry, chemical works, power plant and mining etc.
执行标准 Standards applied
IEC 60092-376 IEC 60228 Class2 IEC 60092-351 IEC 60092-359 IEC 60332-3-22 IEC 60754 IEC 61034 | – 设计 – 导体 – 绝缘 – 护套 – 阻燃 – 无卤 – 低烟 | Design Conductor Insulation Sheath Flame Retardant Halogen Free Low Smoke |
结构 Construction
组分 Components | 代号 Code | 质料/形貌 Material/Description |
系列代号 Series code | CH | 船用通讯电缆 Shipboard symmetrical communication cable |
导体 Conductor | 绞合镀锡退火铜，IEC 60228 Class 2 Stranded tinned annealed copper (STC), IEC 60228 Class 2 | |
绝缘 Insulation | J | 交联聚乙烯 XLPE, IEC 60092-351 |
内护套 Inner sheath | PJ | 无卤阻燃热固性子料 Halogen-free flame retardant thermoset compound (SHF2) |
PF | 无卤阻燃热塑性子料 Halogen-free flame retardant thermoplastic compound (SHF1) | |
铠装 Armor | 8 | 镀锡铜丝编织 Tinned copper wire braid (TCWB) |
9 | 镀锌钢丝编织 Galvanized steel wire braided (GSWB) | |
外护套 Outer sheath | 0 | 无外护套 Without outer sheath |
5 | 无卤阻燃热固性子料 Halogen-free flame retardant thermoset compound (SHF2) | |
6 | 无卤阻燃热塑性子料 Halogen-free flame retardant thermoplastic compound (SHF1) | |
外护套颜色 Outer sheath color | 玄色(若有) Black, if any | |
燃烧特征 Flammability | SC | 低烟无卤阻燃 LSHF Flame retardant, IEC60332-3-22(CAT.A) |
