环保船用电缆
CJV/NA船用电缆系列
CJV/NA船用电缆系列
0.6/1kV
交联聚乙烯绝缘电力电缆
XLPE insulated shipboard power calbe
图例 Example:
CJV92/NA
3X120
型号：
Type:
CJV/NA
CJV80/NA
CJV90/NA
CJV82/NA
CJV92/NA
用途 Application
船用电力电缆可用于河海种种船舶及海上石油平台等水 上修建的电力照明和一样平常控制装置之用 。对冶金、化工 、电力等工矿企业亦同样适用 。
The cable is intended for power lighting and control system of shipboard and off-shore building such as oil platform. It is also available to metallurgical industy, chemical works, power plant and corporation mining
etc
结构 Construction
执行标准 Standards applied
IEC 60092-353 IEC 60228 Class2 IEC 60092-351 IEC 60092-359 IEC 60331 IEC 60332-3-22 | – 设计 – 导体 – 绝缘 – 护套 – 耐火 – 阻燃 | Design Conductor Insulation Sheath Fire Resistant Flame Retardant |
组分 Components | 代号 Code | 质料/描述 Material/Description |
系列代号 Series code | C | 船用电力电缆 Shipboard power cable |
导体 Conductor | 绞合镀锡退火铜， IEC 60228 Class 2 Stranded tinned annealed copper (STC), IEC 60228 Class 2 | |
绝缘 Insulation | J | 耐火云母带+交联聚乙烯 Mica glass tape + XLPE, IEC 60092-351 |
内护套 Inner sheath | V | 聚氯乙烯 PVC |
铠装 Armor | 8 | 镀锡铜丝编织 Tinned copper wire braid (TCWB) |
9 | 镀锌钢丝编织 Galvanized steel wire braided (GSWB) | |
外护套 Outer sheath | 0 | 无外护套 Without outer sheath |
2 | 聚氯乙烯 PVC | |
外护套颜色 Outer sheath color | 玄色(若有) Black, if any | |
燃烧特征 Flammability | NA | 耐火 Fire resistant, IEC60331 |
